| Physical characteristics | |
| Height | 44 mm |
| Width | 482 mm |
| Depth | 150 mm |
| Weight | 1.96 kg |
| Enclosure | Bended metal |
| Operating Temperature | 0 à +50 °C |
| Ports features | |
| Vitesse des ports | 1000 Mbps |
| Détection des ports | Auto-negotiation, MDI/MDIX |
| Status Report | |
| DMX Port | 12 |
| Connectivity | |
| Ethernet Ports | 2 |
| Contact closure | 1 x terminal block |
| Connector Type | Neutrik 5 pin XLR |
| Power | |
| Consumption | 20W maximum |
| Fuse | Fusible temporisé 1A 250V |
| Power | 100-240VAC, 50-60Hz and PoE (802.3af) |
| Ethernet features | |
| Supported protocols (Ethernet) | Art-Net I, Art-Net II, Art-Net III, Art-Net IV, sACN (ANSI E1.31), RTTRpL (BlackTrax) |
| DMX features | |
| DMX Port Isolation | Optic and galvanic isolation per port |
| Backup DMX | Yes |
| Environment | |
| Humidity | 5-95% non-condensing |
| Storage Temperature | -10 à +70 °C |
| Network features | |
| Profile manager | Yes |
| ReRoute | Yes |
| Snapshot | Yes |
| Softpatch | Yes |
| Merging Engine | Yes |
| Trigger system | Yes |
| Backup DMX | Yes |
| Processing engines | 12 |
| Master / Limit | Yes |
| Approvals | |
| Approvals : green | RoHS, Reach |
| Approvals : electromagnetic emissions and immunity | EN55032 class A, EN55035, EN61000-3-2, EN61000-3-3, EN61000-4-2, EN61000-4-4 ,EN61000-4-5, EN61000-4-11, FCC Part 15 CFR 47 class A |
| Approvals : Safety | IEC 60950-1, EN 60950-1, UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 62368-1, EN 62368-1, UL 62368-1, CAN/CSA-C22.2 No. 62368-1, CE |
LumiNode - User Manual- 3.1 Mb
